Winna Yellow-Green Grounding Wire Harness (High Conductivity Safety Ground Wire) is a high-performance grounding connection component designed for industrial electrical systems, power equipment, and new energy devices. It uses high-quality yellow-green dual-color insulation sheath and high-conductivity copper core conductor to ensure low resistance and high reliability grounding path, effectively preventing static accumulation, leakage, and lightning damage. Widely used in distribution cabinets, photovoltaic inverters, electric vehicle charging piles, data center cabinets, and building electrical grounding systems, meeting global safety standards.
Technical Specifications
| Conductor Material | High-purity oxygen-free copper (copper content ≥99.95%) |
| Insulation Sheath | Yellow-green dual-color PVC/TPE (temperature resistance -40°C to +105°C) |
| Cross-sectional Area Range | 1.5mm² – 50mm² (AWG 16 – AWG 1/0) |
| Rated Voltage | 600V / 1000V (depending on wire gauge) |
| Standard Length | 0.3m – 5m (customizable) |
Product Features
- High Conductivity: Multi-strand stranded copper core design with extremely low resistivity ensures stable and reliable grounding loop.
- Dual Safety Identification: International standard yellow-green dual-color sheath clearly distinguishes ground wire, avoiding misconnection risk.
- Weather Resistance and Flame Retardancy: Insulation material passes UL VW-1 flame retardant test, oil-resistant, acid-alkali resistant, UV-resistant.
- Flexible and Easy to Install: Wire harness has high flexibility, suitable for wiring in narrow spaces, supports terminal pre-crimping or custom connectors.
Application Scenarios
Industrial Power Distribution and Control Systems
Used for grounding busbar connection in distribution cabinets, MCC cabinets, PLC control cabinets, ensuring operator and equipment safety, complying with IEC 60364 grounding standards.
New Energy and Electric Vehicle Facilities
Grounding circuit for photovoltaic inverters, energy storage systems, charging piles, effectively discharging lightning-induced current and fault current, improving system EMC performance.
Frequently Asked Questions
What is the difference between yellow-green grounding wire harness and ordinary black wire?
Does Winna grounding wire harness support custom length and terminals?
Does the product have international safety certifications?
About Winna Technology
Winna Technology specializes in power adapters, AC/DC cable harness customization, and ultrasonic metal welding equipment R&D and manufacturing, providing one-stop OEM/ODM services.
Our products are CE/UL/FCC/CCC/RoHS certified, with an annual return rate below 0.02%, serving customers in 50+ countries and regions worldwide.
Wire Harness Customization & Processing Flow
From requirement confirmation to finished product delivery, 10 processes with strict checks at every stage ensure each wire harness meets the highest quality standards
We have comprehensive wire harness customization and processing capabilities, covering the entire process from requirement confirmation to finished product delivery. The following is the standard wire harness processing workflow, with strict quality control standards at each step to ensure product consistency and reliability.
Confirm Requirements, Start with Precision
Before production, engineering confirms the specifications based on the customer's drawings and specifications. Any pending items are communicated with the customer to resolve production questions before finalizing the manufacturing process, ensuring every step is accurate.
Cutting Precision Down to the Millimeter
Cut wires (cables) to the required length and coil them. Operators carefully verify the specifications on the production work order before cutting, using calibrated advanced equipment to ensure the processing quality of each wire.
Professional Stripping, Precision Pre-Soldering
Remove the wire jacket (outer sheath) and any unnecessary fillers. Use a professional pneumatic wire stripper to strip the jacket, then perform pre-soldering. Adjust the equipment precisely according to each wire specification to ensure zero damage to the core conductor.
Secure Connection, Reliable Transmission
Crimp the terminal to the wire (cable) core conductor. Use a professional terminal crimping machine, with dedicated crimping dies for different terminals. Strictly adjust the machine and check the crimping specifications before operation to ensure each terminal connection is firm and reliable.
Fine Assembly, Quality Assurance
According to the engineering drawing, sort the crimped core wires, assemble them into the connector housing, and reinforce the wire harness strength. All processing methods strictly follow the engineering drawing and SOP, using specialized tools to ensure consistency.
Full Traceability at a Glance
Attach labels containing information such as specifications, ID, and serial number to each customized wire. Labels help assembly personnel quickly find the corresponding interface and facilitate future traceability of production history, enabling full-process digital management.
Self-Inspection & Peer Check, Layered Control
After assembly, perform self-inspection during wire harness production based on the production work order drawings and dimensions, ensuring all manufacturing details are confirmed. Every step is recorded, and every link is traceable.
Four-Wire Testing, Zero Defects Outgoing
All completed wire harnesses undergo continuity testing, resistance measurement, wire position measurement, and insulation resistance testing using a four-wire electrical tester. They are only released after confirming normal electrical characteristics, ensuring each wire harness meets design standards.
Digital Archiving, Traceable Quality
Record and archive images of the finished wire harness. Production engineering data and appearance are digitally archived for easy future review, modification, or addition. Digital management ensures precise reproduction of wire harnesses with the same specifications.
Safe Protection, On-Time Delivery
Carefully package with cushioning materials to ensure no damage during transportation, and ship according to the specified method. Full tracking from packaging to logistics ensures products are delivered safely and on time to the customer.
