The automotive door handle wiring harness is an important component connecting the door handle to the vehicle control system, responsible for transmitting door lock, sensor, and button signals. This product uses high-purity copper conductors and flame-retardant PVC insulation, offering excellent conductivity and anti-interference capability, ensuring stable connections during frequent door opening and closing. Product Features: High reliability: crimped with a fully automatic terminal machine, low contact resistance, plug and pull life exceeding 100,000 cycles. Environmental resistance: operating temperature range -40°C to +105°C, oil-resistant, corrosion-resistant, suitable for harsh vehicle conditions. Flexible customization: length, terminal type, and sheath specifications can be customized according to different vehicle door handle structures. Electromagnetic compatibility: twisted wire design effectively suppresses electromagnetic interference, ensuring pure signal transmission. Technical Specifications: Rated voltage: DC 12V / 24V. Rated current: 3A (single circuit). Conductor specification: 0.35mm²0.5mm² pure copper stranded wire. Insulation material: PVC (RoHS compliant). Protection rating: IP56 (connector part). Terminal material: tin-plated brass. Application Scenarios: This product is widely used in electric door handles, hidden door handles, keyless entry systems, and door lock control modules for passenger cars, commercial vehicles, and new energy vehicles. Compatible with mainstream vehicle series such as Toyota, Volkswagen, BYD, etc., and offers OEM/ODM customization services to meet automotive wiring harness processing project needs.
Technical Specifications
| Parameters | Please consult sales for detailed specifications |
Product Features
- Please contact sales for detailed product features
Application Scenarios
- Home Appliances and Consumer Electronics
Custom power cords, signal wires, and ribbon cables, meeting ROHS/REACH environmental standards, suitable for white goods and small appliances. - Automotive Electronics and New Energy
Automotive wiring harnesses, sensor harnesses, high-voltage connection harnesses, passing TS16949 quality system, high temperature and vibration resistant. - Industrial Automation and Equipment
Robot harnesses, servo motor harnesses, drag chain cables, high flexibility and bending resistance, suitable for complex industrial environments. - Medical Device Harnesses
Medical-grade harness customization, biocompatible materials, precision terminal crimping, suitable for monitors, ultrasound equipment, etc.
